The 2-axis stabilization turntable
Author：Repunite Technology Click：39 Release time：2025-01-27
The 2-axis stabilization turntable is designed for radar equipment to maintain target alignment during movement, suitable for vehicle and ship-mounted applications. The turntable integrates inertial navigation systems or uses carrier attitude data for compensation, covering applications such as large ship-mounted equipment.
Key Specifications | |
Resolution | 0.01° |
Accuracy | 0.1° |
Speed | Azimuth: ≤50°/s |
Elevation: ≤30°/s | |
Accelerated speed | ≤30°/s² |
Max. Payload Weight | ≤300kg |
Power Consumption | ≤3kw |
Weight | ≤270kg |
